Reliability testing is an activity undertaken to assess the functional reliability of a product over a specified life period and under all circumstances, such as intended use, transportation or storage. It is to expose the product to natural or artificial environmental conditions to be subjected to its action, so as to evaluate the performance of the product in the actual use, transportation and storage of environmental conditions, and analyze and study the degree of influence of environmental factors and their mechanism of action. Through the use of a variety of environmental test equipment to simulate the climate environment of high temperature, low temperature, high temperature and high humidity and temperature changes, accelerate the reaction of the product in the use of the environment, to verify whether it has reached the expected quality objectives in the research and development, design, manufacturing, so as to evaluate the product as a whole, to determine the product reliability life.

Reliability test classification

Classification of reliability test: climate, power, outdoor environment, design verification test, etc.

1. Climate and environment testing

High temperature test, low temperature test, temperature and humidity cycle/constant humidity and heat test, hot and cold shock test, rapid temperature change test, low pressure test, optical aging test, corrosion test, etc.

2. Mechanical environment test

Vibration test, impact test, crash test, drop test, etc.

3. Comprehensive environment test

Temperature + humidity + vibration, HALT/HASS/HASA, temperature and humidity stacking test, high-pressure cooking test, etc.

4. Testing of packing materials and packaging transportation

Ambient temperature and humidity test, stacking test, packaging compressive test, vibration test, impact test, drop test, crash test, horizontal clamping test, low pressure test, etc.

5. IP defense test

Dustproof test, waterproof test, etc.

6. Physical performance test

Grid test, wear test, scratch test, plug and pull test, bending test, color fastness test, fire/combustion test; Swing test, key life test, hardness test, drop weight impact/pendulum impact test, tensile strength/compressive strength/yield strength test, melt index test, etc.

7. Electrical performance test

Temperature rise test, voltage resistance test, insulation resistance test, dielectric strength test, contact resistance test, surface resistivity test, grounding resistance test, etc.

Harmonized Standards

Xenon lamp aging test

ISO4892.2, GB/T 16422.2, ASTM G 155, ASTM D4459

Ultraviolet aging test

ISO 4892.3, GB/T 16422.3, ASTM G 154, ASTM D 4674

Salt spray test

GB/T 2423.17, IEC 60068-2-11, GB/T 10125, ISO 9227, ASTM B 117, GB/T 2423.18, IEC 60068-2-52, ASTM B 368, MIL-STD-202, EIA-364-26, PV 1210, GB/T 2423.18-2000, GB/T 10587-2006, GB/T 6461, GJB 150.11-86, GB 6458, GB 6459, GB 6460, GB 5938, GB 5939, GB 5940, GB 1771, etc.

High temperature test

GB/T 2423.2, IEC 60068-2-2, EN 60068-2-2

Low temperature test

GB/T 2423.1, IEC 60068-2-1, EN 60068-2-1

Rapid temperature change test

GB/T 2423.22, IEC60068-2-14

Cold and heat shock test

GB/T 2423.22, IEC60068-2-14, EIA-364-32

Constant heat and humidity test

GB/T2423.3, IEC 60068-2-78, EN 60068-2-78

Temperature change test

GB/T 2423.22, IEC 60068-2-14, EN 60068-2-14

Alternating damp-heat test

GB/T 2423.4, IEC 60068-2-30, EN 60068-2-30

Alternating humidity and humidity combined cycle test heat

GB/T 2423.34, IEC60068-2-38, MIL-STD-202

Temperature/humidity cycle

GB/2423.34, IEC 60068-2-38, EN 60068-2-38

Sinusoidal vibration

GB/T 2423.10, IEC 60068-2-6, EN 60068-2-6, ISO 8318, GB/T 4857.10, ISO 2247, GB/T 4857.7

Random vibration

GB/T 2423.56, IEC 60068-2-64

Impact test

GB/T 2423.5, IEC 60068-2-27, GB/T 2425.6

Crash test

GB/T 4857.20

Drop test

GB/T2423.8, IEC 60068-2-31

Three comprehensive test

GB/T 2423.35, GB/T 2423.36

Gas corrosion test

EIA-364-65, GB/T 2423.51, IEC 60068-2-60
