Reliability test is an activity to evaluate the functional reliability of products in all environments such as expected use, transportation or storage within the specified service life. It refers to exposing the product to natural or artificial environmental conditions to withstand its effects, so as to evaluate the performance of the product under the environmental conditions of actual use, transportation and storage, and to analyze and study the impact degree and mechanism of environmental factors. By using various environmental test equipment to simulate the high temperature, low temperature, high temperature, high humidity and temperature changes in the climate environment, accelerate the reaction of the product in the use environment to verify whether it meets the expected quality objectives in the research, development, design and manufacturing, thus evaluating the overall product to determine the product reliability life.

Reliability test classification：

Reliability test classification: climate, power, outdoor environment, design verification test, etc.

1. Climate environment test

High temperature test, low temperature test, temperature and humidity cycle/constant humidity and heat test, cold and heat shock test, rapid temperature change test, low pressure test, light aging test, corrosion test, etc.

2. Mechanical environment test

Vibration test, impact test, collision test, drop test, etc.

3. Comprehensive environmental test

Temperature+humidity+vibration, HALT/HASS/HASA, temperature and humidity stacking test, high-pressure cooking test, etc.

4. Packaging materials and packaging transportation test

Environmental temperature and humidity test, stacking test, packaging compression test, vibration test, impact test, drop test, collision test, horizontal clamping test, low air pressure test, etc.

5. IP protection test

Dust proof test, waterproof test, etc.

6. Physical performance test

Baige test, abrasion test, scratch test, plugging test, bending test, color fastness test, fire/combustion test; Swing test, key life test, hardness test, drop hammer impact/pendulum impact test, tensile strength/compressive strength/yield strength test, melt index test, etc.

7. Electrical performance test

Temperature rise test, voltage withstand test, insulation resistance test, dielectric strength test, contact resistance test, surface resistivity test, grounding resistance test, etc.

Relevant test standards：

Xenon lamp aging test

ISO4892.2、GB/T 16422.2、ASTM G 155、ASTM D4459

UV aging test

ISO 4892.3、GB/T 16422.3、ASTM G 154、ASTM D 4674

Salt spray test

GB/T 2423.17, IEC 60068-2-11, GB/T 10125, ISO 9227, ASTM B 117, GB/T 2423.18, IEC 60068-2-52, ASTM B 368, MIL-STD-202, EIA-364-26, PV 1210, GB/T 2423.18-2000, GB/T 10587-2006, GB/T 6461, GJB 150.11-86, GB 6458, GB 6459, GB 6460, GB 5938, GB 5939, GB 5940, GB 1771, etc.

hot test

GB/T 2423.2、IEC 60068-2-2、EN 60068-2-2

Low temperature test

GB/T 2423.1、IEC 60068-2-1、EN 60068-2-1

Fast temperature change test

GB/T 2423.22、IEC60068-2-14

Thermal Shock Test

GB/T 2423.22、IEC60068-2-14、EIA-364-32

Constant damp heat test

GB/T2423.3、IEC 60068-2-78、EN 60068-2-78

Temperature change test

GB/T 2423.22、IEC 60068-2-14、EN 60068-2-14

Alternating damp heat test

GB/T 2423.4、IEC 60068-2-30、EN 60068-2-30

Combined cycle test heat of alternating humidity, temperature and humidity

GB/T 2423.34、IEC60068-2-38、MIL-STD-202

Temperature/humidity cycle

GB/2423.34、IEC 60068-2-38、EN 60068-2-38

Sinusoidal vibration

GB/T 2423.10、IEC 60068-2-6、EN 60068-2-6、ISO 8318、GB/T 4857.10、ISO 2247、GB/T 4857.7

random vibration

GB/T 2423.56、IEC 60068-2-64

Impact test

GB/T 2423.5、IEC 60068-2-27、GB/T 2425.6

Crash test

GB/T 4857.20

Drop Test

GB/T2423.8、IEC 60068-2-31

III. Comprehensive test

GB/T 2423.35、GB/T 2423.36

Gas corrosion test

EIA-364-65、GB/T 2423.51、IEC 60068-2-60
